Hybrid inverter LuxPower GEN-LB-EU 6K (6 kW, 48 V, 1 phase)

41,856

Hybrid inverter LuxPower GEN-LB-EU 6K 6 kW The LuxPower GEN-LB-EU 6K 6 kW hybrid inverter is a modern solution for home and small commercial solar power plants with 48 V batteries. Two powerful MPPT trackers, support for lithium and lead batteries and IP65 protection class make it suitable for both indoor and outdoor installation. The inverter supports smart operating modes and parallel connection of up to 10 devices, allowing the system to scale with your consumption.

  • Connector typeGB/T
  • Power plugIndustrial 3PIN
  • Power7 kW
  • Amperage6-32 A

Немає в наявності

LuxPower GEN-LB-EU 6K is designed specifically for modern home and small commercial solar installations where it is important to flexibly manage energy flows. The inverter can operate as a classic grid-tie device with surplus sales, as a stand-alone inverter powered by batteries and a generator, and as a powerful UPS that instantly takes over the load when the grid voltage drops. This allows you to combine savings on electricity bills with the stability of power supply to critical consumers.

Two independent MPPT trackers with a wide input voltage range allow you to connect up to 8 kW of solar panels. You can spread the arrays of panels on different sides of the roof and get stable generation throughout the day. The inverter operates with a 48-volt battery bus, supporting both lithium modules with BMS and classic lead-acid batteries. Due to its high charge/discharge currents, the device is well suited for systems with large battery packs.

A special feature of the GEN-LB-EU series is the support of smart energy management modes: you can set the priority of power from the sun, battery or grid, set up scheduled battery charging (for example, during the night cheap tariff) and limit the output to the grid to the required values. The IP65-rated enclosure is suitable for both indoor and outdoor installation, and the built-in Wi-Fi/RS485/CAN allows the inverter to be integrated into an ECOFACTOR or manufacturer's monitoring system.



  • Weight 29 kg
  • Dimensions 45,5 × 46,7 × 18,1 cm
  • Manufacturer / model

    LuxPower GEN-LB-EU 6K

  • Inverter type

    Hybrid, on/off-grid, UPS function

  • Rated power output

    6 kW, 1 phase (230 V)

  • Rated voltage of the battery

    48 V, 40-60 V range

  • Max. power of solar panels

    8 kW

  • Number of MPPTs

    2 (≈120-500 IN MPPT)

  • Max. battery charge/discharge current

    up to 120 / 120 A

  • Protection class / efficiency

    IP65 (outdoor installation)

  • Max. MAX. EFFICIENCY

    up to ~97.3 %
